Documentation & annotation

Tag everything still untagged

Tagging hundreds of elements by hand eats the afternoon — and the one you missed prints blank on the issued drawing.

Catch tags that would print blank

A tag whose parameter is empty — or whose host vanished from a link — still sits on the drawing. It looks placed. It prints nothing.

Untangle overlapping tags

A one-pass tag dump drops every mark on the element origin. The drawing looks finished until you zoom in.

Dimension chains without duplicates

Re-running a dimensioning routine stacks duplicate strings. Two different pairs can share a length, so length is no way to deduplicate.

Spot elevations and coordinates

The agent cannot know a view’s origin, so a view-plane [u, v] is not a usable contract. Sections make it worse.

Keynote a found set

A keynote on an element with an empty Keynote parameter prints nothing. Approving “place 40 keynotes” when twelve are empty is how a drawing goes out looking finished.
