Views & drawing production
Create consistent views, apply templates and frame the exact elements you need.
-
Look at a found set
Moving the camera closer looks obvious and does nothing. In an orthographic 3D the extent decides the zoom — a section box is how you move in.
-
Apply view templates in bulk
Half the floor plans picked up the office template. The other half still show the working view. You find out at issue.
-
Dependent views and crop splits
A long plan needs dependents. After the first split the only index that reliably names the remaining unsplit part is 0, and an exact 0.5 / 0.5 is a known refusal.
-
Cut sections on a found set
Create section with no line cuts everything. You wanted a cut through one stair, and you got a building-wide section named Section 47.
